Type |
347cc,
2-Stroke Twin, Liquid Cooled, Reed Valve |
Bore x Stroke |
64mm x
54mm |
Compression Ratio |
6.5:1 |
Fuel Delivery |
Dual
Mikuni 26mm |
Ignition |
CDI |
Starting System |
Kick |
Transmission |
6-Speed
Manual Clutch |
Drive Train |
2WD;
Sealed O-Ring Chain |
 |
|
Suspension / Front |
Independent Double Wishbone, 9.1 w/ 5-way Preload
Adjustment |
Suspension / Rear |
Swing
Arm, 8.7 w/ Rebound, Compression and Threaded Preload
Adjustment |
Brakes / Front |
Dual
Hydraulic Disc |
Brakes / Rear |
Hydraulic Disc |
Tires / Front |
AT21 x
7-10 |
Tires / Rear |
AT20 x
10-9 |
 |
|
L x W x H |
73.0 x
43.3 x 42.5 |
Seat Height |
31.5 |
Wheelbase |
50.4 |
Ground Clearance |
5.3 |
Fuel Capacity |
3.2
Gallons |
Dry Weight |
386 Lbs. |
 |
|
Lighting |
Dual 30W
Krypton Multi-reflector Headlights & 21/5W Brake light |
Warranty |
3 Month
(Limited Factory Warranty) |
